Cylinder TRAIL BIKES aluminum diameter 52mm with studs center distance HONDA.
- Height of the cylinder: 63mm
- Height of the skirt : 26,5mm
- Outside diameter of the skirt: 55mm
This cylinder is designed to be mounted with a 41,4mm stroke crankshaft.
No need to re-bore the lower engine, this cylinder mounts without modification of the lower engine on HONDA and Chinese from 50cc to 110cc.
Contrary to the photo no indication of displacement is visible.
High quality manufacturing TRAIL BIKES reference : TBW0156
